Seiko SPT RC1536L 25-225pl Printhead

Name: Seiko SPT RC1536L 25-225pl Printhead
Brand: SEIKO
Price: 2478.0000 USD
Availability: InStock

rating

(0 reviews)Write a review

$ 2,478.00

Brand: SEIKO
Product Code: fprarirp208
Availability: In Stock

This printhead is suitable for for ceramic, corrugated cardboard, textiles, inkjet printers. The following items are expressly excluded from warr..

Qty

Free Shipping

Ships Today

Easy

Returns

Lowest Price

Guarantee

Description

This printhead is suitable for for ceramic, corrugated cardboard, textiles, inkjet printers.

The following items are expressly excluded from warranty coverage:

defects related, in any way, to the use of non-original inks

clogged, missing or deviated nozzles

defects related to misuse, abuse, accident, neglect, lack of use, or improper storage when not in use for extended periods

defects related to failure to perform periodic maintenance as specified in the user documentation; operation for unintended purposes

defects related to improper loading of media

all other defects, failures or damage not considered manufacturing defects

defects related to third-party applications, software, parts, components, or peripheral devices, including any bulk ink system.

defects that are merely cosmetic in nature.

Product Specifications

Drop Volume Range :

RC1536-M* = 13 to 150 pL

RC1536-L* = 25 to 225 pL

Maximlum Productivity at 10 Drops:

RC1536-M* = 1.500 µL/sec

RC1536-L* = 2.477 µL/sec

Discharge at 25M/min

RC1536-M* = 60 g/m²

RC1536-L* = 85 g/m²

(*RC1536A-M and RC1536A-L for WATER-based ink)

Possible print directions: Vertical and Horizontal

Number of Grey Levels: up to 10

Jetting Frequency: up to 37 kHz

Native Nozzle Resolution: 360 npi

Active Nozzles: 1536 at 4 rows

Ink Inlets / Ink Outlets : 1/1

Ink Compatibility: Oil-, UV-, Solvent- and WATER-based

Print width: 108.3 mm

Weight: > 0.7 kg

Dimensions: 180,0 x 47.6 x 123.3 mm

Driving Interface: Parallel interface

This printhead carries a manufacturer warranty.

Country of origin : Japan

It is highly recommended to replace the head cables together with a new printhead.

Seiko SPT RC1536L 25-225pl Printhead
