Mimaki ME-300STII

Name: Mimaki ME-300STII
Brand: MIMAKI
Price: 700.0000 USD
Availability: InStock

rating

(0 reviews)Write a review

USD 700.00

Brand: MIMAKI
Product Code: fp6ac3p208
Availability: In Stock

Product Description The long-awaited high precision desktop engraving machine.Simultaneous 3-axis interpolation meets the needs of users includin..

Qty

Free Shipping

Ships Today

Easy

Returns

Lowest Price

Guarantee

The long-awaited high precision desktop engraving machine.
Simultaneous 3-axis interpolation meets the needs of users including precise engraving and modeling.

The desktop engraving machine ME-II Series provides advanced functions, e.g. 3D modeling with 3-axis interpolation, and a sensor is installed for controlling engraving depth.
To match necessary workpiece size, three different machine sizes are offered.

Plotting and cutting commands are installed.

Various CAD data are supported.

Three different machine sizes, A4, A3 and A2-plus.

Servo motors are installed to X, Y and Z axes and deliver high torque and precision engraving.

Wide range of applications including name plates, control panel covers and prototype making.

Three different sizes for various applications

ST type for hard materials

ME-300STII

Maximum engraving area: 310 x 220 mm (12.2 x 8.7")

ME-500STII

Maximum engraving area: 483 x 305 mm (19.0 x 12.0")

ME-650STII

Maximum engraving area: 650 x 440 mm (25.6 x 17.3")

A cutter (Φ6.0) is able to engrave hard materials.

Cut out letters, letter engraving, modeling and many cutting methods are available with knives and end mills up to Φ6.0 mm.

ME-300STII

Maximum engraving area: 310 x 220 mm (12.2 x 8.7")

ME-500STII

Maximum engraving area: 483 x 305 mm (19.0 x 12.0")

ME-650STII

Maximum engraving area: 650 x 440 mm (25.6 x 17.3")

ME-300STII

ME-500STII

ME-650STII

Maximum Engraving Area

310 x 220 mm (12.2 x 8.7")

483 x 305mm (19.0 x 12.0")

650 x 440mm (25.6 x 17.3")

Maximum workpiece thickness

50mm (2.0")

X-Y Axis

Maximum Speed

Engraving

60mm/sec (2.4"/sec)

Moving

80mm/sec (3.1"/sec)

Acceleration

Engraving

0.05G

Moving

0.3G

Mechanical Resolution

0.5μm

Z Axis

Maximum Z stroke

60mm (2.4")

Maximum speed

30mm/sec (1.2"/sec)

Mechanical Resolution

0.25μm

Spindle

Maximum rotation

14,000rpm

Spindle Rotation

7000-14,000rpm

Maximum Material Weight

20kg (44lbs)

Command

MGL-IIc3*1、MGL-Ic1*2

Receiver Buffer Size

27MB

Interface

USB2.0, RS-232C

Power Requirement

AC100V-240V 50/60Hz

Power Consumption

450VA or less

Operating Environment

Temperature: 5-40ºC, Humidity: 35-75% (Rh) No condensation

Certifications

VCCI class A / RoHS

Dimensions (W x D x H)

540 × 630 × 530mm (21.3 x 24.8 x 20.9")

785 × 750 × 530mm (30.9 x 29.5 x 20.9")

880 × 960 × 530mm (34.6 x 37.0 x 20.9")

Weight

50kg (110.2lbs)

82kg (180.8lbs)

95kg (209.4lbs)

Standard accessories

Name

Item number

Quantity / Volume

FLATNESS CORRECTION ADJUSTER

MP-M500505

Clamp

SPA-0019

Spanner

14*17

Spanner

10*12

Plus driver

No.2-100

Heagonal wrenches

AWS-0770

Double-sided tape

MP-NO.532 ハバ＝8

Power cable

100 V

Grounding adapter 15A/125V AC

MP-YL-212

Operation manual

Warranty certificate

Desk tray

Hubo-1200

Dust cleaning hose ASSY

Engraving cutter ST 0.4

SPB-0010

Engraving cutter holder ST Φ6

SPA-0021

Dust cleaner (Large)

SPA-0015

Dust cleaner (Small)

SPA-0016

Brush for spindle motor

SPC-0024

Specifications are subject to change without notice.

All trademarks or registered trademarks are the property of their respective owners.

Installing and training of the product are available at additional costs.
